Writing Delphi Components - Creating and Installing Packages

See menu Component, Install Packages in the IDE. Please make sure to set your Delphi library path correct that it includes the folder where these DCU files. A package is a special dynamic-link library used by applications, the IDE, or both.Runtime packages provide functionality when a user runs an application.Design-time packages are used to install components in the IDE and to create special property editors for custom components.A single package can function at both design time and runtime, and design-time packages frequently work by calling.

If you want your components to have a design time presence (placed on the toolbar and be able to set parameters via the Object Inspector), then they must be placed in a package and installed in the IDE.

Though it is not documented anywhere, you need to know that packages can only be installed in the same version of Delphi that was used to compile them. (The *.dcu files are version dependent.) This means that if you share some component

either you release the source code (so it can be installed in any version)
or you compile a package in every version of Delphi (including those that are not yet released)

Of course, this brings up the question of how to make components available in C++ Builder. (Maybe I'll figure this out later.)

Installing Components - Single Directory Manual Installation Example, Debugging
Creating a Package Creating a Package Collection
Supporting Multiple Delphi Versions References

Installing Components

You'd think this was documented somewhere. (Actually, the help contains a significant amount of information on this. However, it is very difficult to find and to understand.)

(In the help, you can try Installing component packages. However, it does not mention the required resource file. To find this, search the help for installing components, select Compiling components into packages, and click on Installing component packages.)

To use a unit in another program, all you need is the *.dcu (Delphi Compiled Unit) file. Components are a bit more complicated - they need to be registered so that their icons will be displayed on the toolbar, and they need to execute at design time so that they can paint themselves and make appropriate property assignments.

To accomplish this, you will need at least 2 files in addition to the *.dcu files - PackageName.bpl, and PackageName.dcp. If any of the included units include a resource file (either *.res or *.dcr), then all those files will also be necessary. (See Creating a Package to generate these.)

64114, (816 523 The Intel 8080A is a complete 8-bit parallel central processing unit (CPU). MISSOURI: Kansas City, 8080 Ward Pkwy, Kansas Ci MO. It is fabricated on a single. NOTICE: This is a produc&ion data sheet. This book contains detailed specifications for 111 semiconductor memory.

PackageName.dpk, PackageName.dcu, and the *.pas files included in the package do not need to be distributed. (They are used to build the package, they are not needed to use it.)

Then Install the package using

Component / Install Packages

Install

Package

Notes:

The *.bpl (Borland package library) file resources can be read by the Resource Hacker.
dcl_xxx - Design time Component Library, xxx should identify you or your company
Your dcl_xxx.bpl files reference vcl50.bpl.
*.dcp and *.dcu files must be in the Delphi Library Path.
When present, an *.dpc (package collection) file contains the other files (dcp, dcu, bpl). Therefore, it is the only file needed. (Note that dpc <> dcp.)
To add your component to an existing package,
- Select File / Open.. / *.dpk
- Add the appropriate source files
- Press compile

Single Directory Manual Installation Example

Under C:Program FilesBorlandDelphi5, create the directories Packages[PackageName]
Enter the directory via Tools / Environment options.. / Library / Library path
I used - $(DELPHI)Packages[PackageName]
Copy [PackageName].bpl and [PackageName].dcp to the new directory
Install the package via Component / Install Packages..
- Press the Add button
- Select your bpl file (the default directory is C:Program FilesBorlandDelphi5Projects)
- At this point, the component(s) will be visible in the tool bar and can be placed on a form .. however, the form won't compile
For each *.pas file listed in [PackageName].dpk, copy the corresponding *.dcu file to the new directory
Copy each *.dcr file listed in [PackageName].dpk to the new directory
If there are any actions, copy the associated *.dfm files to the new directory (these contain the icons)
Copy the help files (hlp, toc, cnt) to the new directory and install (link) them

Runtime Packages

Project / Options.. / Packages / Build with runtime packages

windows

You can place a copy of the *.bpl file in one of these directories

Ext	Description	Comment
pas	Pascal source code	Do not need to distribute, but required to step through the code during debug
dcu	Delphi Compiled Unit	One for each pas-file. Must distribute if the exe does not call the associated bpl-file(dll-file). (Project / Options.. / Packages / Build with runtime packages is disabled.) There is also a dcu-file associated with the dpk-file. How to unlock fl studio 20 from demo mode free. This one should not be distributed.
bpl	Borland package library	Run-time dll, must distribute. Also used when Project / Options.. / Packages / Build with runtime packages is enabled.
dcp	Delphi compiled package	Must distribute, used at Design-time, contains Design-time code for all the dcu-files
dpk	Delphi package	Source file that defines the package. Create via File / New.. /New / Package.
pce		dpc	Delphi Package Collection	This is a collection of the files needed to install one or more packages. Create this using Tools / Package Collection Editor.
hlp toc cnt

Path on my system	Extensions
C:Program FilesBorlandDelphi5Bin	bpl, dll
C:Program FilesBorlandDelphi5ProjectsBpl	its up to you
C:Program FilesBorlandDelphi5Projects	exe (default output directory)
Same directory as your exe	exe (custom output directory)

or you can modify your system's search path (I don't recommend this).

In one test case (just a simple form), the exe file was 15 kb using bpl's, and 356 kb using dcu's. (In another test, just a form and no components, it was 14 kb and 298 kb.)

Debugging

When developing components, be sure to have the *.dcu file in the search path

Project / Options.. / Directories / Search path

In order to debug a component (set break points), the *.dcu and *.pas files should be in the same directory or at least the source file needs to be in the Debug Source Path (Project / Options.. / Directories).

In order to step through vcl code, the *.dcu files are already in the search path. Therefore, you only need to include the *.pas files in Delphi5SourceVcl in the Debug Source Path.

It appears that there may be a small difference between machines. Today (5-2003), I had to enable the use of Debug DCUs in order to step through the VCL files - Project / Options.. / Compiler / Use Debug DCUs - and Delphi5SourceVcl was NOT in the Debug Source Path. I don't know how I was able to step through the VCL before.

Creating a Package

To place a component on the toolbar, you need to create a package.

From the Delphi menu, select
In the package window, make sure that Contains is highlighted and click Add. Include all the applicable *.pas files.
Including *.dcu files (one of the options) seems to have no purpose - it still tries to find the *.pas files when it compiles.
Click the Options button
- On Description tab - the Description should contain a generic identifier that represents your brand and a phrase the describes the package. If this is omitted, then only the filename and path will be displayed when you look at the list of installed packages.
- On Version Info tab - CompanyName, FileDescription, FileVersion - Though these are stored in only the *.dof and *.res files, they should be entered.
Save the package via File / Save. It does not matter if you save the package before or after the files are added, either way, the hideous long path names are used .. I really prefer shorter relative path names. (Delphi 6 uses relative names.)
Press Compile to produce *.dcu files for each *.pas file and one for the package itself. It also produces the *.bpl and *.dcp files.
Use Install to add the package to the Windows registry and place the components on the toolbar.

The package definition is stored as plain text in dcl_xxx50.dpk. You can add additional components by editing and recompiling this file. (By convention, I name package files as dcl_[package_ID][Delphi_Version] - dcl - Delphi Compiled Library.)

By default, your *.bpl and *.dcp files are placed in

In general, this is good because it is already in the necessary path definitions. However, I prefer to keep everything related to a project in a single directory tree. As a result, I suggest that you change to point elsewhere. (BPL output directory is not available in Delphi 6, but appears to be controlled via Packages

DCP output directory.) I suggest a tree something like

I have also used this structure

This will allow you to zip the tree and distribute a smaller file.

I do not suggest using

to change the output directories because that will affect all projects .. and only a specific project should be assigned to a directory that is named for it.

Note: In Delphi 5, the output paths can not be set using the Delphi menu. Instead, you have to manually edit dcl_xxx50.dof (stored in ini file format).

I have tested this with relative paths, as shown above.

Creating a Package Collection

A package collection can contain multiple packages. A package collection contains the required *.dcu files and the optional *.pas and *.res files. It also instructs the installer where to place the files.

However, because the resulting file is over 2 Mb, and redistributes a file (vcl50.bpl) that should never (IMHO) be redistributed, I do not suggest using this. (vcl50.bpl is required for the package to install .. but it is either already on the developer's machine or the user has the wrong version of Delphi. On the other hand, vcl50.bpl is required on an end user's machine if the application is configured to 'Build with runtime packages'.)

To create a new collection, from the Delphi menu, select Tools / Package Collection Editor.

Identify your package collection under Author/Vendor name and add a couple of directories to the Directory list. The Directory name is what appears in the comboboxes. For example

In the editor, select Add a package from either the menu or the toolbar. Once you've included a package, select Add a file group (it helps a lot if you name your group - it gives you something to click on later). You should probably have several groups - the *.dcu files are mandatory, but you might make the source files optional. Click the Auto.. button to locate ALL the source and/or *.dcu files referenced in the package. Now go through and delete all the Delphi files. (My files were at the bottom of the list. I scrolled to the bottom and selected the first Delphi file above my files. Then, I scrolled to the top of the list, held down the shift key, and clicked the first file in the list. I simply deleted the selected files.)

I tried removing vcl50.bpl from the package - then it wouldn't compile.

Supporting Multiple Delphi Versions

The DCU's made for one version of Delphi won't work in another version.

That's right - you must recompile your components for each Delphi version. (I don't remember seeing this in any of the references.)

I tried to install a component compiled in Delphi 5 into Delphi 6 .. an error said that it required vcl50.bpl. So I found that and placed it in C:WINDOWSsystem32, but it is not compatible with vcl60.bpl because they both have the same objects.

As a result, I had to re-compile the source in Delphi 6.

Because of this, I recommend that you always include a Delphi version indicator in the package filename.

This is copied from the Delphi 5 help (from Deploying packages)

vcl.dcp is required. (go figure) The following excerpts are from various *.dpk files

References

Teach Yourself Borland Delphi 4 in 21 Days, good reference.
Creating Components is very good.
DelphiByDesign
Developing Custom Delphi Components
